Joseph Mallord William Turner

Richmond, Yorkshire


In Tate Britain

Prints and Drawings Room

View by appointment
Joseph Mallord William Turner 1775–1851
Watercolour on paper
Support: 391 × 485 mm
Accepted by the nation as part of the Turner Bequest 1856
Turner Bequest CXCVII H

Display caption

This colour study shows the Norman castle at Richmond in Yorkshire, and
the bridge over the River Swale.


Turner visited Richmond in 1816. However, he had sketched the same view nineteen years earlier, when he visited the town
in 1797, so this study may have been made by referring to his old sketchbook. Turner often developed watercolours
from sketches made years earlier. This study was not carried any further and
no completed watercolour of Richmond was made from it.


Gallery label, August 2004

Does this text contain inaccurate information or language that you feel we should improve or change? We would like to hear from you.

Technique and condition

This study was painted on white wove paper with a typical glue size. There are a number of colour trials at the edges, quite thickly painted. It was possible to remove tiny samples the size of a pin-point from these, for organic analysis by Fourier transform infrared microscopy, a technique which creates a ‘fingerprint’ spectrum which can be compared to known materials. This confirmed that the paint medium is a typical gum water, and indicated the presence of the glue size on the paper.
Thin washes of pale blue and yellow were freely applied to very wet paper, until the image evolved and took form without any prior drawing. Brown earth pigments applied as equally diluted washes created the vegetation, in combination with the Prussian blue already used for the sky, and possibly with Indian yellow as well. This traditional pigment would soon be supplanted entirely in Turner’s palette by chrome yellow, which looks similar in its palest shade, but is much less prone to fading. Only the palest shade had been produced by this date, and Turner had already used it in oil in 1814, the year of its invention, in Dido and Aeneas (Tate N00494). There are several mulberry coloured patches of colour at the left hand edge, and this colour has also been used in the landscape. This one is a madder, recognisable in ultraviolet light as was the Indian yellow. The unusual bluish shade of the madder is a result of the unusual laking process used to fix or mordant the dye during pigment manufacture: iron could be detected here. Turner used several madder lake pigments with unusual mordants, and they were all found in his studio after his death. Several faded readily: it is fortunate that this study has not been exposed to much light in the nineteenth century, during which other Turner watercolours faded considerably. The even whiteness of the paper, which shows no evidence of light damage, indicates the good condition of this image.
The identification of iron in the mordant of the mulberry madder was in fact confirmed by placing a tiny sample it in the sample chamber of a scanning electron microscope, under an X-ray beam. This beam interacts with the elements that make up each pigment: pure madder is a dye and no elements would be found unless it were fixed with a mordant. The presence of madder was confirmed by Fourier transform infrared microscopy as described above, through comparison to known materials such as Turner’s studio pigments, which had also been analysed by other methods to identify their dye components.

Helen Evans
October 2008

Revised by Joyce Townsend
March 2011

Catalogue entry

This colour study shares its composition with a watercolour study Turner made much earlier (Tate D01116; Turner Bequest XXXVI V), which was developed from a sketch made during his 1797 tour of the North of England (Tate D01012; Turner Bequest XXXV 9). This and the earlier watercolour make an interesting comparison; in this later ‘colour beginning’ Turner has transformed the earlier scene through a different, luminous, rendering of light and colour.
David Hill and others have classified this work as a study for a watercolour intended for Whitaker’s History of Richmondshire, although no finished watercolour of this view was actually completed.1 Richmond is a subject that Turner must have taken considerable care over with regards to this project, with two alternative views of Richmond eventually engraved.
While Hill dated this sheet c.1816–18 in his 1996 Turner in the North,2 in an earlier publication he suggested a later dating of around 1821, the year that Whitaker died, arguing that the presence of mauve in Turner’s palettes signals a later dating as there is ‘little sign’ of this prior to his first Italian trip in 1819–20.3
See also the introduction to the Richmondshire ‘colour beginnings’ grouping to which this study has been assigned.
Hill, 1996, p.40.
ibid, p. 40.
David Hill in Hill, Warburton, Tussey and others, Turner in Yorkshire, 1980, pp.31–32.
Technical notes:
There is a vertical fold at the centre of the sheet.
Blank, save for inscriptions: stamped in black ‘CXCVII-H’ bottom left; stamped in black with Turner Bequest monogram bottom left; written in red ‘CXCVII. H.’ bottom right.

Elizabeth Jacklin
February 2015
